Invertek ODV-3-240041-3F1A Optidrive ECO Inverter Drive – 1.5kW 3-Phase 400V IP66 TFT Display (Outdoor)
The Invertek ODV-3-240041-3F1A Optidrive ECO is a compact, weatherproof 1.5kW variable frequency drive engineered for efficient motor control in HVAC, fan, and pump systems. With its IP66-rated outdoor enclosure, bright TFT display, and integrated EMC filter, this inverter ensures reliable operation in harsh environments. Designed for precision, energy efficiency, and long service life, the ODV-3-240041-3F1A provides outstanding performance and durability for both industrial and commercial applications.
Key Specifications
Manufacturer: Invertek Drives
Series: Optidrive ECO (ODV-3)
Model: ODV-3-240041-3F1A
Power Rating: 1.5 kW (2 HP)
Input Voltage: 380 – 480 V AC
Input Phases: 3-Phase
Input Current (Continuous): 3.7 A
Recommended Supply Fuse / MCB (Type B): 10 A
Output Current: 4.1 A
Output Voltage: 0 – Supply Voltage
Enclosure Rating: IP66 (Outdoor, Non-Switched)
Display Type: TFT Display
EMC Filter: Internal (Standard)
Brake Transistor: Not Included
PCB Coating: Standard
Cable & Wiring Information
Maximum Supply Cable Size: 8 mm² (0.01 sq in)
Maximum Motor Cable Size: 8 mm² (0.01 sq in)
Maximum Motor Cable Length: 100 m (328 ft)
Mechanical Dimensions
Frame Size: 2
Height: 257 mm (10.12 in)
Width: 188 mm (7.4 in)
Depth: 182 mm (7.17 in)
Weight: 3.5 kg (7.72 lbs)
Fixing Points: 4 × M4 Bolts
Packaged Dimensions
Height: 215 mm (8.46 in)
Width: 235 mm (9.25 in)
Depth: 375 mm (14.76 in)
Weight: 4.2 kg (9.26 lbs)
Features & Benefits
- ✅ 1.5kW output ideal for small-scale HVAC, fan, and pump applications
- ✅ IP66 outdoor-rated design protects against dust, water, and environmental exposure
- ✅ TFT display offers clear, intuitive control and system feedback
- ✅ Built-in EMC filter ensures compliance and minimises electrical interference
- ✅ High efficiency for reduced energy consumption and cost savings
- ✅ Compact design allows for easy wall or enclosure mounting
- ✅ Maintenance-free construction ensures reliable, long-term performance
Typical Applications
- Outdoor HVAC and ventilation systems
- Pumps and compressors
- Fans and blowers
- Irrigation and water treatment systems
- Building automation and control systems
Why Buy from Drive Outlet Megastore
Genuine Invertek Products: 100% authentic Optidrive ECO drives supplied with manufacturer warranty.
Expert Technical Support: Professional guidance for setup, configuration, and commissioning.
Fast UK Delivery: Most models in stock and ready for next-day shipment.
Best Price Guarantee: Found it cheaper elsewhere? We’ll beat it.
Order the Invertek ODV-3-240041-3F1A Optidrive ECO 1.5kW Outdoor Inverter Drive Today
Fast UK delivery, competitive trade pricing, and expert technical assistance on all Invertek Optidrive ECO inverters.
Contact us for live stock and trade pricing
